High Power 80kw Dual Gun Wallbox DC Fast Charging Station With Intelligent APP Monitor For Commercial Parking Hub

Short Description:

MIDA Dual Gun EV Charging Station provides high-efficiency power (40kW-80kW) for commercial fleets. Features dual CCS2/GBT guns for simultaneous charging, 150-1000V wide voltage range, and OCPP 1.6J/2.0.1 smart management. IP55 weatherproof for reliable outdoor public parking and workplace charging.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Optimized Fleet Management

Reduce downtime with MIDA’s smart load balancing technology. This 40kW-80kW wallbox ensures intelligent power distribution between dual CCS2/GBT guns, making it an ideal choice for high-traffic workplaces and urban charging zones.

Robust & Weatherproof

Engineered with IP55-rated protection and advanced safety features, MIDA chargers excel in extreme outdoor environments. From input overvoltage protection to output short-circuit defense, we prioritize reliability in every charging session.

Technical Specifications

Parameter	Details
Rated Power	40kW / 60kW / 80kW (Adjustable)
Input Voltage	400Vac ± 15%, 3P + N + PE
Output Voltage Range	150V – 1000Vdc
Max Output Current	200A Max
Charging Interface	Dual Gun (CCS2 / GBT / CHAdeMO Optional)
Power Factor	≥ 0.98 (APFC)
Efficiency	≥ 95%
Communication	4G / WiFi / Ethernet / OCPP 1.6J / 2.0.1
User Interface	10.1-inch LCD Touchscreen / RFID / APP / POS
Protection Grade	IP55 / IK10
Operating Temperature	-25°C to +55°C
