MIDA 1000V 1500A MCS Charging Connector Megawatt Charging System

Short Description:

Revolutionize heavy-duty EV charging with MIDA’s 1500A MCS Connector. Designed for Megawatt Charging Systems (MCS), it supports 1000V DC output, making it the perfect solution for electric trucks, buses, and maritime vessels. Durable, efficient, and future-proof. Inquiry for MIDA MCS technology today!

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

MIDA is at the forefront of the e-mobility revolution with our 1500A MCS (Megawatt Charging System) Connector. Engineered specifically for the next generation of heavy-duty electric vehicles, this connector delivers the massive power required to charge large battery packs in record time.

Key Advantages

Ultra-High Power: Supports up to 1500A continuous current for Megawatt-level charging.
High Voltage Compatibility: Rated at 1000V DC, supporting high-voltage platform vehicles.
Ergonomic Design: Lightweight handle design ensures ease of use despite high power capability.
Safety First: Advanced insulation (≥500MΩ) and wide operating temperature (-30℃ to +50℃).

Technical Data

Rated Voltage	1000V DC
Rated Current	1500A
Insulation Resistance	≥500MΩ 1000V DC
Standard	MCS (Megawatt Charging System)
Operating Temperature	-30℃ to +50℃
