Reliable 60kw Nacs Floor Mounted Evse Rfid Card Control With Rfid Card Control For Highway High Performance Module

Short Description:

MIDA 60kW DC Fast Charging Station provides high-speed NACS charging with ultra-wide 1000V DC output. Features rugged IP54 waterproof design, intelligent OCPP 1.6J control, and user-friendly RFID/App management. Ideal for high-traffic public hubs and commercial fleets. CE & TUV certified for safety.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Efficient 60kW DC Fast Charging

Designed for the next generation of e-mobility, this NACS charging station delivers up to 60kW of clean power. Its modular design ensures high uptime and low maintenance costs for operators, making it the perfect choice for highway and commercial deployments.

Multi-Standard Compatibility

Full support for NACS standards, ensuring seamless connection with all modern electric vehicles. Equipped with dual-gun intelligent power sharing, it can charge two vehicles simultaneously at optimized speeds.

Industrial Grade Protection

Built to withstand harsh environments with IP54 and IK10 ratings. Features an 8-layer safety protection system including over-temperature, surge, and leakage current detection for 24/7 safe operation.

Technical Specifications

Rated Power	60kW
Input Voltage	400Vac±10% (3P+N+PE)
Output Voltage	200V – 1000V DC
Max Output Current	250A
Efficiency	>95.5%% at nominal output power
Charging Interface	NACS (CCS1 / CCS2 / CHAdeMO / GB/T / NACS compatible)
Display & UI	10.1″ LCD Touch Screen + RFID + App
Communication	4G / WiFi / Ethernet (OCPP 1.6J/2.0.1 Ready)
Protocol	OCPP 1.6J / 2.0.1
Protection Level	IP54 & IK10 (Outdoor Rated)
Dimensions (LWH)	7006002000mm
