Universal 40kw 80kw Dual Gun DC EV Charger Wallbox Station 380V Fast Charging Pile For Electric Bus And Fleet Vans

Short Description:

MIDA Dual Gun EV Charging Station provides high-efficiency power (40kW-80kW) for commercial fleets. Features dual CCS2/GBT guns for simultaneous charging, 150-1000V wide voltage range, and OCPP 1.6J/2.0.1 smart management. IP55 weatherproof for reliable outdoor public parking and workplace charging.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

Efficiency Meets Intelligence

MIDA’s dual-gun wall-mounted DC fast charger is designed for destination charging hubs. With its compact footprint and powerful 80kW output, it allows two vehicles to charge simultaneously, maximizing turnover for commercial operators and fleet managers.

Built for the Future

Featuring a wide voltage output range from 150V to 1000Vdc, this station is fully compatible with next-gen 800V EV architectures. The integrated 10.1-inch LCD touchscreen provides a seamless user experience for authentication and monitoring.

Technical Specifications

Parameter	Details
Rated Power	40kW / 60kW / 80kW (Adjustable)
Input Voltage	400Vac ± 15%, 3P + N + PE
Output Voltage Range	150V – 1000Vdc
Max Output Current	200A Max
Charging Interface	Dual Gun (CCS2 / GBT / CHAdeMO Optional)
Power Factor	≥ 0.98 (APFC)
Efficiency	≥ 95%
Communication	4G / WiFi / Ethernet / OCPP 1.6J / 2.0.1
User Interface	10.1-inch LCD Touchscreen / RFID / APP / POS
Protection Grade	IP55 / IK10
Operating Temperature	-25°C to +55°C
