44KW Dual Type 2 Socket AC EV Charger Wallbox OCPP RFID

Short Description:

MIDA 44KW dual-socket AC EV wallbox simultaneously charges two EVs at 22KW each. Features 5" LCD touchscreen, dual RFID readers, OCPP 1.6J protocol, and WiFi/Ethernet/4G connectivity. IP55 & IK08 rated for outdoor durability. CE certified. Ideal for high-traffic commercial charging stations and fleet operations.

Send email to us Download as PDF

Product Detail

FAQ

Product Tags

44KW Dual Socket AC EV Charger Wallbox

The MIDA 44KW Dual Socket AC EV Charger is a high-capacity commercial charging solution that powers two electric vehicles simultaneously at up to 22KW per socket. Designed for heavy-traffic environments — shopping centers, corporate campuses, fleet depots, and public charging networks — this wallbox maximizes throughput while minimizing footprint.

Why Dual Charging?

One unit, two independent charging sockets. Serve twice the vehicles with half the installation cost and wall space. Each socket operates independently with its own RFID reader, energy meter, and charging session — no waiting, no sharing limitations.

Key Features

44KW Total Output: Dual independent 22KW three-phase outputs — charge two EVs at full speed simultaneously.
Smart Dual Management: Two independent RFID readers and energy meters for separate user authentication, billing, and session tracking per socket.
5″ LCD Touchscreen: Professional-grade display with clear dual-socket status monitoring, real-time charging data, and intuitive user guidance.
OCPP 1.6J Ready: Full backend integration via WiFi, Ethernet, or 4G. Remote monitoring, OTA firmware updates, load management, and diagnostics.
Flexible Access Control: Plug & Charge, dual RFID card readers, and mobile App — choose the right mode for each user group.
Enterprise-Grade Safety: Type A 30mA RCD + 6mA DC leakage protection per socket, PE grounding detection, built-in temperature sensors with auto-derating.
Built to Last: IP55 weatherproof enclosure with IK08 impact resistance and tempered glass front panel — engineered for 24/7 outdoor operation from -30°C to +55°C.
Class 1.0 Metering: High-precision onboard metering for accurate per-socket energy tracking and billing.

Technical Specifications

Parameter	Specification
Model	EV044Y2-A3
Rated Power	44KW (22KW + 22KW)
Input Power	3P+N+PE, 400V AC ±20%, 50/60Hz, 64A
Output per Socket	380V AC, 32A (3-phase)
Number of Sockets	2 × Type 2 Socket (IEC 62196-2)
User Interface	5″ LCD Touchscreen + LED + Dual RFID
Communication	WiFi / Ethernet / 4G (optional)
Protocol	OCPP 1.6J (OCPP 2.0 optional)
RCD Protection	30mA Type A + 6mA DC (Type B optional)
Metering Accuracy	Class 1.0 per socket
Ingress Protection	IP55
Impact Protection	IK08
Enclosure Material	PC Plastic + Tempered Glass Front Panel
Installation	Wall-mount / Pole-mount
Operating Temperature	-30°C to +55°C
Operating Humidity	5% ~ 95% (non-condensing)
Product Dimensions	460 × 310 × 180 mm
Net Weight	13 kg
Certification	CE (EN/IEC 61851-1:2017, EN/IEC 61851-21-2:2018)
Warranty	2 Years
Standby Power	< 3W
