AC Charging Socket EV Charger Socket for Electric Car Charger U-EV16S

Short Description:

Model: V3-U-EV16P
1. Rated Current:16A
2. OperationVoltage:AC 250V
3. Insulation Resistance:>500MΩ(DC500V)
4 Withstand Voltage:2000V
5.Contact Resistance:0.5mΩ Max


Product Detail

FAQ

Product Tags

AC Charging Socket EV Charger Socket for Electric Vehicle Charger   -EV16P

Features 1. Comply GB/T 20234-2006 regulations and requirements
2. Nice appearancehand-held ergonomic designeasy plug
3.Excellent protection performance,protection grade IP44(working condition)
4. Non-detachable shell protection,protection grade IP44
Mechanical
Properties
1. Mechanical life : no-load plug in/pull out10000 times
2. Coupled insertion force: ≤80N
Electrical
Performance
1. Rated Current16A
2. Rate Voltage250V
3. Insulation resistance:>500MΩDC500V
4. Terminal temperature rise:<50K
5. Withstand Voltage2000V
6. Contact Resistance 0.5mΩ Max
7. Operating temperature: -30°C~+50°C
Applied Materials 1. Case Material: Thermoplastic,flame retardant grade UL94 V-0
2. Conntact bushCopper alloy,silver plating
Model selection and the standard wiring
Model Rated Current Cable Specigication
U-EV16S 16A 3 X 2.5mm²
